Why does SMD type led tact switches uses the heat-resisting material

  Why does SMD type led tact switches uses the heat-resisting material? At present,our SMD TS8 illuminated tact switches’s base uses PA66 material but it cann’t withstand higher than 260 degrees Celsius,so we are trying to find a better raw material to substitute it. The Features:As we all know the PA9T is a special Polyamide engineering plastics,it has excellent thermostability and it’s a forming material that withstands repeated friction and sliding resistance,it also named as PA9T,that belongs nylon plastic. the lowest hydroscopicity in Nylon series resin. Stable size,it won’t make size change and decrease the mechanical strength as for the water absorption. High thermostability,it’s widely used for lead-free solder and it won’t makes any bubble when you use 280℃ tin test. primary liquidity. Low gas, less than other nylon resin is difficult to pollute and corrode the mold, prolong the use of the mold. Fast crystallization speed and short cooling time. In high temperature environment

Mini 5.8*5.8 LED Latch Type Push Button Switch

 Mini 5.8*5.8 LED Latch Type Push Button Switch FVWIN electronics is leading manufacturer of illuminated tact switch and led push button switch ,we are not only supply the momentary led tactile switch but also offer the self locking switch button. The brief specification Model:PB58-0000X Circuit:2P2T Size:5.8*5.8*10.2mm Current:0.1A 30VDC Lifespan:10,000 cycles Min Actuation Force:180±50gf Travel:1.9mm±0.2mm LED Colors:red,blue,green,white,yellow Feature: miniature size is easy for PCB mount and save the space of PCB Multiple led colours option Latching function We are the professionally maunfacturer of various illuminated tactile switch and LED push buttons for widely application,more design request,pls feel free to contact us. http://www.fvwindz.com

ILLUMINATED BUTTON SWITCH FOR BROADCAST PANEL

FVWIN INTRODUCES TS15 SERIES NEW LED ILLUMINATED PUSH BUTTON SWITCH FVWIN, the leading manufacturer of high reliability electromechanical switches, now,we announced the availability of its new  TS15 Series illuminated tactile push button switch .      TS15 is adding to FVWIN’s current range of   illuminated LED tact button switches ,it comes in a 12*12mm /15*15mm square size, it has red,blue,yellow,white and green six different single LED options as well as customized legends on the top caps,the illuminated button offers vertical thru-hole types with 200K long-life cycles;     What’s more,the transparent clear cap makes the light emits even illumination; It’s ideal for a wide range of applications such as matrix controller,LED video processor, video broadcast systems and more. Key features: · Two different outline sizes offering more choices for design. · Integrated LEDs is convenient for designing the illumination model,many LED colors options. · Providing the most common types actuat

THE ILLUMINATED TACT SWITCH FOR BROADCAST CONTROL PANEL BUTTON

   THE ILLUMINATED TACT SWITCH FOR BROADCAST CONTROL PANEL BUTTON FVWIN Electronics released the TS10-005X17X series illuminated tact switch,this button switch provides a 500,000 cycles expected lifespan,crystal button cap,single and bi-color LED options and through hole pcb mount. The applications and market for the button switch covers pro audio&video equipment,LED video processor,matrix controller,HD video processor,telecommunication equipment,instruments,industry control panel and so on. Brief specification for TS10-005X17X series LED tact button switch as follow: Circuit:SPST Rating:12VDC 50mA Contact Resistance:100m Ω Max Insulation Resistance:100 M Ω 250VDC for 1 MIN Dielectric Strength:250VAC(50/60HZ) for 1 MIN Life Test:500,000 cycles Actuation Force:250 ± 100gf Travel:0.25 ± 0.1mm Function:momentary   TS10-005X17X product detail page   TS10-005X17X datasheet   Click Fvwin Electronics at www.fvwindz.com . we can offer the customized engraved logo service as per your reques

Console panel button with illuminated push switch

  console panel button with illuminated push switch The below picture is our common controller video processor panel button with illuminated led push switch,it mainly has square 11mm,12mm,15mm,17mm four sizes options for your design;which has transparent concave button surface,even lighting effect,long or short travel. more info,pls click http://www.fvwindz.com

12*12MM Broadcast illuminated Backlit Pushbutton Switches

12*12MM Broadcast illuminated Backlit Pushbutton Switches These Audio / Video illumianted push   buttons  switches  feature s   concave , engraved , square caps in two common sizes 12*12mm and 15*15mm for design flexibility in LED System Solutions applications ,g old plating contacts terminals   in sure s  high reliability and long operations   life of 200 thousand. Model:TS15-9W56WTX Size:12x12x13.1mm Rated:12VDC ,50mA Contact R esistance :100mΩ(max) Insulation R esistance :100MΩ(min) Withstand V oltage :250VAC for 1 minute Operation Force:250±50gf Total Travel:0.4±0.15mm Function:OFF-(ON) Soldering Temperature:260℃ for 3 seconds Using Temperature:-20℃ ~  70℃ Life:2000,000 cycles Feature: 1.  High quality  concave 12mm/  15mm /16mm /17mm   flat  clear button 2.  Adjustable red,blue,white,green   and yellow LED backlight 3.  Front-panel configurable function buttons with multiple LED colors   4.  B acklighting and field-replaceable legends 5.  Applicated for video integration,AV system

Fvwin TS7 Series Bi-color / RGB LED illuminated Tact PCB Button Switch
